Toyota Sienna Service Manual: Accessory meter
COMPONENTS
Installation
1. INSTALL COMBINATION METER ASSEMBLY
Connect the connectors.
Install the combination meter assembly with the 4
screws.
2. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMB ...
Calibration
1. SELECT COMPASS DISPLAY MODE
The MODE switch allows you to select the Display
or Non-display mode of the compass.
HINT:
In compass display mode, the display indicates
outside temper ...
